CAD/CAM

Creative has the capability to be involved with each project—from design to first shot.  Our Engineering Department is staffed with the highest quality mold engineers, using today’s latest software. Learn more

CAD Department

Our Cad Department consists of 8 dual Intel Xeon Cad Workstations, operating Siemens NX Unigraphics.

CAM Department

On-site Server Room
On-site Server Room

Our Cam Department has 3 dual Intel Xeon Cam Workstations operating Siemens NX Manufacturing Package.

CAD/CAM data transfer methods and compatibility:

Unigraphics can import/export NATIVE NX FILES, PARASOLID, STEP, SOLIDWORKS, DWG and DXF files.

Data can be transferred in 4 ways:

  1. Via our ftp site on the Internet;
  2. Via your ftp site on the Internet;
  3. Via USB Memory Drive;
  4. CD ROM/ DVD ROM

NOTE: For security and data management reasons, Creative Die Mold cannot accept cad or zip files via email attachment. Please contact Alex Gospodarek  at 630-790-9731 for FTP information / data transmission options.
